RLS16-3-24-11

Compare Ask a question

Ask a Question

* Required fields

 Size guide Share
RLS16-3-24-11

RLS16-3-24-11

Regular price $0.00
Sale price $0.00 Regular price
Unit price
Product description

CAT NO.

 Type of Lamp Number of Lamps Rating of each lamp

RLS16-3-24-11

   A     B   C   D

SBCFL Or SBLED

 E26 Medium base TL-09 120V 40W Max

A

 Series designation, "RLS18" for 18 AWG cord, "RLS16" for 16 AWG cord or"RLS14" for 14 AVG cord.

B

 No. of conductors, 2 or 3

C

 No. of lamp holders and lamps provided, min, 7, max. limited by conductor size and lamp rating
See below and ELECTRICAL RATINGS for details.
18 AWG =max. 960 Watts total for string light (e.g. 24 lamps rated 40 W, or 87 lamps rated 11W)
16 AWG =max. 1200 Watts total for string light (e.g. 30 lamps rated 40W, or 109 lamps rated 11W)
14 AWG=max. 1440 Watts total for string light (e.g. 36 lamps rated 40w, or 130 lamps rated 11W)

D

 Lamp wattage rating, in watts (actual watt consumption for SBLED and SBCFL, not incandescent-equivalent wattage output).
